Forums >> Revit Building >> Technical Support >> Wall Detail Level

Search this ThreadSearch this Thread | Page 1 of 1 |

Mon, Oct 27, 2008 at 5:28:03 PM | Wall Detail Level

#1

maranelloboy


active

Joined: Mon, Oct 8, 2007
57 Posts
3 Stars: 2 Votes


Is there any way of changing what layers of a wall (or floor or roof for that matter) display on the different detail levels?  Our consultants want more simplified walls than what we're sending them in our CAD exports, but they still need to be able to have the wall core defined.  The first picture is what we get with the detail level set to medium and fine, the second picture is set to course, and the third picture is the desired result at medium.

Attached Images


This user is offline



Mon, Oct 27, 2008 at 6:53:52 PM | Wall Detail Level

#2

WWHub


site moderator|||

Joined: Tue, May 16, 2006
13079 Posts
3.5 Stars: 363 Votes


Look at your export-layers file.  Structure 1&2 / Finish 1&2 / air-layer / membrane as well as common edges are all definable layers.... you can set up what will work best for you by experimentation.



You just need to understand what hapens when you move items from core to finish or the oter way around.  Your HELP will explain the rules on cleanup using these values.


This user is offline



Mon, Oct 27, 2008 at 7:14:53 PM | Wall Detail Level

#3

maranelloboy


active

Joined: Mon, Oct 8, 2007
57 Posts
3 Stars: 2 Votes


Thanks.  I'll try it out.

This user is offline



Mon, Oct 27, 2008 at 7:24:41 PM | Wall Detail Level

#4

tim123


active

Joined: Tue, Apr 12, 2005
1310 Posts
4.5 Stars: 18 Votes


If there aren't too many walls you can create a duplicate view for the client and use the pen tool to make the lines that you don't want invisible.

This user is offline

View Website

Mon, Oct 27, 2008 at 7:25:20 PM | Wall Detail Level

#5

maranelloboy


active

Joined: Mon, Oct 8, 2007
57 Posts
3 Stars: 2 Votes


Thanks.  I'll try it out.

This user is offline



Mon, Oct 27, 2008 at 7:25:34 PM | Wall Detail Level

#6

tim123


active

Joined: Tue, Apr 12, 2005
1310 Posts
4.5 Stars: 18 Votes


If there aren't too many walls you can create a duplicate view for the client and use the pen tool to make the lines that you don't want invisible.

This user is offline

View Website
