Coil / Spring / Helix

I noticed on the other coils that have been uploaded that their technique wasn’t perfect, and it made a squished wire profile. It isn’t very prominent unless the pitch of the helix is larger than the diameter. In this version I corrected it by modeling the cross-section with ellipses using trigonometry.


Everything is parametric including the diameter of the helix, diameter of the wire, height, number of coils, and material.

CSI Division: 99 Uncategorized
RevitCity Division: Uncategorized

Product Version: Revit Architecture 2020

Uploaded By: ZachLarson
Uploaded On: Thu, Jul 9, 2020
Original Creator: Zach Larson
