A Christmas present for my Animal Research Facility and Laboratory Facility architect friends.

Metal Guardrail (4" standard height, but can be adjusted).  Three types:

1 1/2" projection

3" projection (most used in real life)

6" projection

Adjustable parameters include: Length, Height above floor, Bracket Spacing, Visibility of 'in' and 'out' brackets for dealing with inside and outside wall corners.  For very short walls choose very short bracket spacing (I recommend making yourself a simpler version).

Context image also shows the Broom Stow (previously uploaded).  Masonry wall stack bond pattern and a hollow metal door and frame with lite and louver help to make for a realistic image.
