Forums >> General Discussion >> Revit Project Management >> Massing - making a 'noodle' shape

Search this ThreadSearch this Thread | Page 1 of 1 |

Fri, Apr 20, 2012 at 3:22:32 PM | Massing - making a 'noodle' shape

#1

godisgay


active

Joined: Mon, Mar 22, 2010
9 Posts
No Rating


Hey all,

I'm making an intricate Revit mass representation of a prefabricated building unit. The unit will need to have 4 "noodle" shaped components which will be used to anchor cables coming from another component of the building structure. My questions are...

1. How can I make a noodle shape - shaped in section like the letter "C," so not exactly a half-circle - in Revit mass modeling? (also note, i'm not making this in a Family, just making it in the project itself...)

which brings me to my second question

2. Is there a way I can save this intricate mass as a family AFTER creating it in my project?



Your help is greatly appreciated! Huzzah for Autodesk. Huzzah for 3D.


This user is offline



Fri, Apr 20, 2012 at 3:46:15 PM | Massing - making a 'noodle' shape

#2

WWHub


site moderator|||

Joined: Tue, May 16, 2006
13079 Posts
3.5 Stars: 388 Votes


Why in a mass instead of a family?

No, you can not convert a mass to a family.



Noodle shaped?  Seems like a rectangle profile septh along a path.


This user is offline



Fri, Apr 20, 2012 at 4:08:39 PM | Massing - making a 'noodle' shape

#3

godisgay


active

Joined: Mon, Mar 22, 2010
9 Posts
No Rating


Uh, didn't really catch any of that second part...


This user is offline



Mon, Apr 23, 2012 at 8:16:01 AM | Massing - making a 'noodle' shape

#4

teafoe5


site moderator|||
teafoe5 Avatar

Joined: Fri, Nov 12, 2010
1749 Posts
4.5 Stars: 46 Votes


 A noodle shape? Something like the attached?  It was created using a sweep.



Attached Images


This user is offline

View Website

Mon, Apr 23, 2012 at 6:11:00 PM | Massing - making a 'noodle' shape

#5

itsmyalterego


active
itsmyalterego Avatar

Joined: Thu, May 28, 2009
829 Posts
4 Stars: 16 Votes


Massing is only for ridiculously organic forms.  The vast majority of curves and bends and such can be made with the normal modeling tools within your project.  Sometimes it takes a little creativity to figure out how to make it.



Massing is sort of... separate from the rest of the program.   It's frustrating trying to integrate massing into a project, and it's really only meant as a framework to apply things like roofs and curtain walls to the face of.


This user is offline
