Forums >> Revit Building >> Technical Support >> Side-curved roof
|
|
|
active
Joined: Tue, Aug 4, 2009
70 Posts
No Rating |
Hey,
Anyone knows how to create a roof that has slight curve around the perimeter? Such as the images below?
Anna
|
This user is offline |
|
 | |
|
|
active
Joined: Wed, Mar 5, 2008
208 Posts
 |
You can create an in-place roof family for that, or if it is simple enough, you can use roof fascia for the same purpose.
|
This user is offline |
|
|
|
active
Joined: Tue, Aug 4, 2009
70 Posts
No Rating |
I'm trying to make a roof similar to the second image..I thought of trying Roof Extrusion. But I don't know how to create it.
|
This user is offline |
|
|
|
active
Joined: Wed, Mar 5, 2008
208 Posts
|
Check Your Help file and search roof by extrusion
|
This user is offline |
|
|
|
active
Joined: Tue, Aug 4, 2009
70 Posts
No Rating |
Does not seems to work..T.T
|
This user is offline |
|
|
|
active
Joined: Tue, Aug 4, 2009
70 Posts
No Rating |
I GOT IT!
thx!
|
This user is offline |
|
|
|
active
Joined: Tue, Aug 4, 2009
70 Posts
No Rating |
Anyone a more effective way to create curved edge on both sides of the roof? I'm tried to get the effect of the second image i posted earlier..
I tried using roof extrusion..see file's north part of the house.
Anna
|
This user is offline |
|
|
|
site moderator|||
Joined: Tue, May 16, 2006
13079 Posts
 |
Just run an in-place sweep around the roof. I would do it as an in-place family - roof category.
|
This user is offline |
|
|
|
active
Joined: Wed, Mar 5, 2008
208 Posts
|
Roof by extrusion should do the job, if not, you can try create an in-place roof family.
Go to component --> model in place --> select catagory --> Roof, then model the way you want it.
|
This user is offline |
|
|
|
