Forums >> Revit Building >> Technical Support >> Printing Images on my TitleBlock..???

Search this ThreadSearch this Thread | Page 1 of 1 |

Tue, Feb 15, 2011 at 1:51:37 AM | Printing Images on my TitleBlock..???

#1

CRB14


active

Joined: Fri, Oct 22, 2010
86 Posts
No Rating


Hi there - I have asked before and tried a number of options, but my logo and image that I want on my titleblock still fails to print. I've tried both jpegs and png, raster vs vector and still no success. I've attached files below and the images show in my Revit file but will never print. Any more ideas?

Thanks



Attached Images


Attached Files

This user is offline



Tue, Feb 15, 2011 at 9:24:14 AM | Printing Images on my TitleBlock..???

#2

gebber


active
gebber Avatar

Joined: Thu, Jan 24, 2008
144 Posts
5 Stars: 4 Votes


I gues the problem is coused by the lines you used as outher lines.

I'm not sure what these are but I can't delete or measure them.

When I aline them with the outher lines I drew myself there was no problem at all.



This user is offline

View Website

Tue, Feb 15, 2011 at 9:31:24 PM | Printing Images on my TitleBlock..???

#3

CRB14


active

Joined: Fri, Oct 22, 2010
86 Posts
No Rating


Thank you - I need to ask a question.....do you mean to say you deleted the outer lines, and redrew them so that they could be adjusted/measured etc and then it worked to print using the images as jpegs and pngs? As I mentioned in my earlier post, the titleblock looks perfect on screen, even the outside lines, but then will not print our logo and image of the house.....

 Thanking you for your assistance!


This user is offline



Wed, Feb 16, 2011 at 7:49:30 AM | Printing Images on my TitleBlock..???

#4

gebber


active
gebber Avatar

Joined: Thu, Jan 24, 2008
144 Posts
5 Stars: 4 Votes


when I opend the file there was a line in the left top of the screen, outside the sheet.

I was unable to delete the line but I aligned it with an other line and put it under this line.

Best might be to start from scratch and copy the entire titleblock in here.


This user is offline

View Website

Wed, Feb 16, 2011 at 4:24:54 PM | Printing Images on my TitleBlock..???

#5

cadman6735


active
cadman6735 Avatar

Joined: Thu, Nov 13, 2008
148 Posts
5 Stars: 4 Votes


CRB

The line is a title border line, the one that comes with the family template you can not delete.  How you got one seperated from the title block starting square is a sort of mistory, you must have split the title border line in your building of your border because it is acting like the system title border line.

Any way, I managed to make the line small and move it on top of an existing line to hide it.  to avoid plot centering issues.

The line was locked by a dimension so it was constrained to the title border, when you move the line the bottom border line moved as well.  turning on dims and unlocking fixed this issue.

I had no issue printing the image....  I print with vector and I think, since revit 2010, the software knows if an image is attached to the file and will switch itself from vector to raster when an image is detected, no need to manualy change it.

Here is the altered titel border and a pdf of the print



I hope it works for you



-----------------------------------

  • Ability is what you're capable of doing.
  • Motivation determines what you do.
  • Attitude determines how well you do it.

Quote by:  Holtz, Lou

  • Life is all about the attitude´╗┐

This user is offline
